Narrow v-belt inquiry

Narrow section StarkLine® v-belts are produced as cogged belt for the better action on smaller pulley. Narrow v-belts are taller than the classic ones, therefore they contact on larger surface of the pulleys. StarkLine® belts meet all relevant international standards: DIN 7753, ISO 4184.

Technical description:

section section size length range MDP** La Lp*
XPZ 9,7x8 mm 700-40000 mm 56 mm Li+50 Li+38
XPA 12,7x10 mm 700-40000 mm 70 mm Li+62 Li+45
XPB 16,3x14 mm 700-40000 mm 112 mm Li+82 Li+60
XPC 22x18 mm 1000-40000 mm 180 mm Li+113 Li+83

* Lp = Ld = Lw; **MPD = Minimum Pulley Diameter

If you would like to order StarkLine® v-belts with unique length please fill the inquiry form below.
